Replacement Parts for Oster Turbo 2 Speed A-5 (78005-314-002)
106942
(Diag. #1) Cover Plate Self Tapping Screw
$1.04
41664
(Diag. #1) Screw
$1.04
115286-010-799
(Diag. #2) Molded Cover-Midnight Blue
$5.15
41676
(Diag. #3) Oiler
$3.14
42563
(Diag. #4) Oil Wick
$1.04
44946-005
(Diag. #6) Lever
$3.11
45515
(Diag. #7) Link
$2.23
41723
(Diag. #8) Lever Grease Seal
$0.38
55168-005
(Diag. #9) Brush Cap- Burgundy
$1.27
111012-080
(Diag. #9) Brush Cap- Midnight Blue
$1.56
42584-025
(Diag. #10) Brush & Spring Assbly(1pr.)
$4.43
42566
(Diag. #11) Thrust Plate
$0.32
105520
(Diag. #12) Gear
$20.22
57022-005
(Diag. #13) Housing-Burgundy
$26.72
58543
(Diag. #14) Thrust Washer- Gear
$0.32
44941
(Diag. #15) Hinge Assbly.
$11.34
41665
(Diag. #16) Screw- Hinge Assbly.
$0.41
45588
(Diag. #17) Blade Guard
$1.83
44956
(Diag. #18) Lower Blade #10
$18.00
44959
(Diag. #18) Lower Blade #40
$18.00
58775
(Diag. #19) Top Blade for #10 blade
$7.34
59200
(Diag. #19) Top Blade for #40 blade
$8.91
42571
(Diag. #20) Blade Guide
$1.07
45501
(Diag. #21) Tension Spring
$3.14
44936
(Diag. #22) Socket
$4.71
42555
(Diag. #25) Blade Screw
$1.04
57070
(Diag. #26) Bearing
$1.06
42568
(Diag. #27) Washer-Felt
$1.04
58519
(Diag. #29) Bearing Retainer
$1.04
41719
(Diag. #30) Ball
$1.41
42872
(Diag. #31) Screw
$1.04
42114-050
(Diag. #31) Screw
$1.04
104978
(Diag. #32) Armature
$33.85
84936-000
(Diag. #33) Field Assy.
$30.83
44938
(Diag. #34) Blade Lock / Latch
$5.04
42557
(Diag. #35) Locating Ring
$3.14
42559
(Diag. #36) Thrust Spring Cup
$1.76
42562
(Diag. #37) Thrust Spring
$0.41
58006
(Diag. #38) Motor End Frame Assy
$13.65
42570
(Diag. #42) Retaining Cup
$1.04
58172-005
(Diag. #44) Switch
$8.40
108780-020
(Diag. #46) End Cap Cool Run.- Burgundy
$3.23
108780-080
(Diag. #46) End Cap Cool Run.- Midnight Blue
$3.91
41756
(Diag. #47) Lockwasher
$1.04
42574
(Diag. #48) Screw
$1.04
42113-015
(Diag. #48) Self Tapping Screw- End Cap
$1.04
41683
(Diag. #49) Switch Nut
$1.04
42614
(Diag. #50) Brush Retainer Assbly
$2.04
42573
(Diag. #51) Bale
$1.79
42551
(Diag. #52) Retaning Ring
$2.61
110737
(Diag. #55) Cord/Plug Assbly.
$7.30
42564
(Diag. #62) Screw- Field Contact
$1.04
109682
(Diag. #75) Screw
$1.04
41738
(Diag. #76) Lockwasher
$1.04
58125
(Diag. #78) Label
$1.56
58355
(Diag. #79) Terminal Bracket
$1.04
111013-080
(Diag. #80) Air Filter- Blue
$3.66
111013-020
(Diag. #80) Air Filter- Burgundy
$2.09
58870
(Diag. #81) threaded brass insert for hinge screw (Not Shown)
$1.04
