Replacement Parts for Andis (AGCL) Light Clipper (23175)
64250
(Diag. #1) Cord Set (14Ft.)
$18.06
23175-02
(Diag. #2) Housing - Lower (Black)
$3.95
23175-03
(Diag. #3) Housing - Upper (Black)
$6.09
22267
(Diag. #5) Hanger Bail
$0.57
64945
(Diag. #6) Rear Motor Frame
$6.28
23231
(Diag. #7) Motor Frame - Front
$10.35
21063
(Diag. #9) Insulator- Switch
$0.50
27847
(Diag. #10) Brush with shunt
$2.61
65806
(Diag. #11) Brush Spring
$0.29
65805
(Diag. #12) Brush Retaining Clip
$0.44
27198
(Diag. #13) Motor Frame Clip
$0.44
22453
(Diag. #14) Field Assembly
$36.50
21067
(Diag. #15) Small Bearing Cup
$0.34
21068
(Diag. #16) Bearing Cup - Large
$0.34
15766
(Diag. #17) Blade Drive Screw
$0.34
22086
(Diag. #18) Rear Mounting Screw (Short)
$0.48
27864
(Diag. #22) Blade Hinge Screw
$0.34
23232
(Diag. #23) Screw - LED Holder
$0.48
64535
(Diag. #24) Lock Keeper
$1.39
64537
(Diag. #25) Blade Lock / Latch
$1.76
64606
(Diag. #26) Front Housing Screw (Long)
$0.36
S63897
(Diag. #27) Hinge Assembly
$22.05
60083
(Diag. #28) Oil Seal
$0.96
65828
(Diag. #29) Screw- Switch Assbly.
$0.34
17091
(Diag. #30) Self-Adhesive Foam Pad - Drive Cap
$0.95
64003
(Diag. #32) Blade Bracket / Socket
$1.85
64027
(Diag. #33) Guide - Blade
$0.25
64013
(Diag. #34) Tension Spring
$1.47
64139
(Diag. #35) Screw - Blade (2 Required)
$0.69
23131
(Diag. #36) LED Holder
$3.74
